Remove fishing line from T200

We occasionally find fishing line wrapped around a thruster after a dive. Here are a few quick steps to removing it so you don’t burn out a motor.
If you need to access thrusters 1, 2, 3, or 4, start by removing the fairing covering the mounting bolts. Thrusters 5 and 6 can be accessed without this step.
Remove the four stainless hex bolts holding the thruster to the ROV frame.
Remove the four stainless screws holding the thruster nozzle. If the fishing line doesn’t come away easily at this point, continue disassembling.
Remove the two hex bolts holding the thruster nose cone in place.
Carefully turn the propeller until you see the grub screw holding the propeller and shaft to the motor. Loosen the grub screw with small hex wrench.
Gently pull the propeller shaft assembly away from the motor windings. You will feel resistance from the magnets
Gently unwind the fishing line from around the motor shaft.

Reassemble your T200 and ROV by following these steps in reverse.

Penetrator Wrench Tip

To stop the handle of your penetrator wrench from sliding through the cylinder body, wrap one end in a bit of electrical tape. It’ll save you hunting for it on the floor time after time!

Potting Skills

Joe from Blue Robotics does a great job walking through how to pot a penetrator. Check it out if you are a first-timer or need to brush up on your potting skills:

Remember – we supply Blue Robotics’ thixotropic potting compound and tools!
